PRODUCT DETAILS
intrinsic safety radar vibration composite life detector is the first life detection product integrating two-dimensional biological radar technology and wireless micro-vibration technology for mining in China. It has three detection modes of debris, wall piercing and air, and can realize composite detection and single detection. Its performance index is in the lead in China.
The working principle of composite detection of this product is first, adopting the ultra-wideband impulse radar technology to detect the life parameters like heartbeat signal and inhalation signal, and directly obtain the two-dimensional coordinates of the living body; at the same time, confirming position through the wireless micro-vibration technology, assisted by detecting the audio waves and vibration waves generated by moan, shout, knock, scratch or crawl of survivors under the ground, the waste site, to determine the approximate location area of the trapped people under ground or in the ruins. The effective integration of two-dimensional biological radar and wireless micro-vibration technology can accurately obtain the position of the moving or static living body buried in the mine or under the debris, so as to maximize the detection and rescue effect. The product can be widely used in mine rescue, armed police, forest fire protection, fire prevention and rescue, earthquake and other special industries, conducting emergency rescue missions under mine or in the ruins.
Applicable standards for YSF40 intrinsic safety radar vibration composite life detector:
GB3836.1-2010 electrical equipment for explosive gas atmosphere -- part 1: general requirements
GB3836.4-2010 electrical equipment for explosive gas atmosphere -- part 4: intrinsic safe "I"
MT209 general technical requirements for electrical and electronic products for coal mine communication, testing and control
MT210 basic test methods for electrical and electronic products for coal mine communication, detection and control
